Voltage configurations
|
12 or 24 volts (custom voltages from 10 to 36 volts)
|
Consumption
|
0.2 mA at night, 0.6 mA daytime standby, 2.5 mA when charging
|
Maximum input
|
25 volts (12V control), 50 volts (24V control)
|
Maximum charging current
|
3 Amps DC
|
Typical charging set points
|
Bulk: 14.4 Volts, Float: 13.6 Volts, temperature compensated (custom voltages available)
|
Regulation method
|
Pulse Width Modulation (PWM), Positive side switching
|
Solar LED
|
3 flashes charging, 2 flashes at Bulk Voltage, 1 flash in Float Mode
|
