Temperature range | -40°C to 50°C / -40°F to 120°F |
Case | ABS case, completely sealed in epoxy |
Weight | 100 grams / 3.5 oz. |
Size (H x W x D) | 5.1 x 5.1 x 3.8 cm / 2 x 2 x 1.5 in. (3 inches wide with the tabs) |
Wire | 16 gauge leads, 15 cm (6 in) |
Load LED | 1 flash voltage low, 2 flashes load disconnected |
Voltage configurations | 12 or 24 volts (custom voltages from 10 to 36 volts) |
Consumption | Standby - 0.6 mA, On - 2.3 mA |
Maximum input | 40 volts (12V control), 60V (24V control) |
Maximum load current | 5 Amps DC |
Typical load set points | 13.0 Volts On: 12.0 Volts Off, 60 seconds at or beyond setpoint (custom voltages available) |
