Temperature range | -40°C to 50°C (-40°F to 120°F) |
Case | ABS case, completely sealed in epoxy |
Weight | 50 g (approx. 2oz) |
Size (H x W x D) | 3.8 x 7.0 x 3.1 cm (1.5 x 2.75 x 1.3 in) |
Wire | 18 gauge leads, 5 in long |
Mounting | Wall mountable |
Status light | 1 LED (3 flashes charging, 2 flashes at Bulk Voltage, 1 flash in Float Mode) |
Voltage configurations | 12 or 24 volts (custom voltages from 6 to 36 volts) |
Consumption | 0.2 mA at night, 0.6 mA daytime standby, 2.5 mA when charging |
Maximum input | 40 volts (12V control), 60V (24V control) |
Maximum charging current | 3 Amps DC |
Typical set points | Bulk: 14.4 Volts, Float: 13.6 Volts, temperature compensated (custom voltages available) |
Pulse Width Modulation (PWM) | Regulation method, positive side switching |
